REFRIGERATED COMPRESSED AIR DRYERS
Focused on reliable, constant dew point in all flow conditions. With its excellent heat transfer coefficients and low pressure drop, these dryers provide unparalleled performance for protection your compressed air system, machinery, tools and processes. |
|
FEATURES:
- Lightweight & compact
- Pre-cooling and reheating of compressed air for high efficiency & low energy consumption
- Stainless steel plate heat exchanger (10 – 60 cfm)
- Aluminum block heat exchanger with integrated high efficiency separator (75-200 cfm)
|
- Environmentally friendly R-134a refrigerant
- Refrigerant analyzer gauge
- Heavy-duty industrial powder coated cabinet w/ access panel
|
 |
|
| Item No. |
Capacity (scfm)* |
Connection (in NPT) |
Nominal HP Installed (hp) |
Air-Cooled kW (full load) |
Full Load Amps |
Electrics (Volts-Phase-Hz) |
Height (in) |
Width (in) |
Depth (in) |
Pressure Max (psig) |
Weight (lbs) |
| 82-0010 |
10 |
1/2 |
1/5 |
0.15 |
6 |
115-1-60 |
15 |
16 |
16 |
200 |
71 |
| 82-0015 |
15 |
1/2 |
1/5 |
0.15 |
6 |
115-1-60 |
15 |
16 |
16 |
200 |
74 |
| 82-0025 |
25 |
1/2 |
1/5 |
0.15 |
6 |
115-1-60 |
15 |
16 |
16 |
200 |
76 |
| 82-0040 |
40 |
3/4 |
1/4 |
0.24 |
7 |
115-1-60 |
15 |
16 |
16 |
200 |
78 |
| 82-0150 |
50 |
3/4 |
1/4 |
0.6 |
7 |
115-1-60 |
15 |
16 |
16 |
200 |
80 |
| 82-0160 |
60 |
3/4 |
1/3 |
0.86 |
11 |
115-1-60 |
15 |
16 |
16 |
200 |
102 |
| 82-0175 |
75 |
1 |
1/3 |
0.86 |
11 |
115-1-60 |
22 |
24 |
18 |
200 |
124 |
| 82-01100 |
100 |
1 |
1/2 |
1.33 |
16 |
115-1-60 |
22 |
24 |
18 |
200 |
138 |
| 82-01125 |
125 |
1 |
3/4 |
1.72 |
21 |
115-1-60 |
22 |
24 |
18 |
200 |
156 |
| 82-01150 |
150 |
1 |
3/4 |
1.72 |
21 |
115-1-60 |
22 |
24 |
18 |
200 |
162 |
| 82-01200 |
200 |
1 1/2 |
1 |
1.98 |
12 |
230-1-60 |
30 |
36 |
25 |
200 |
240 |
| * Capacty rated in accordance with CAGI ADF 100 at 100 psig, 100ºF ambient and 38ºF pressure dew point |
|
